1. Product Overview

DIN1480 turnbuckle is a die-forged turnbuckle (also called turnbuckle screw) widely used in rigging and lifting equipment, mainly used to adjust the tension of ropes or chains. Its design complies with the German industrial standard DIN 1480:2005 and is suitable for lifting operations in ships, ports, mines, construction and other fields.

2. Specifications and parameters

– Size range:

– Standard specifications: M5-M64 (slightly different from different suppliers, for example, M6-M56 is covered by the DIN1480:2005 standard).

– Specific models include UU type (hook/hook), OO type (ring/ring), OC type (ring/hook), etc.

– Load capacity:

– Working tension: 0.15T-20T (product parameters of different suppliers are different, some marked maximum loads can reach 24T or even 100T, which needs to be confirmed according to the specific model).

– Safety factor: usually 4-6 times the breaking tension to ensure high-intensity use requirements.

3. Application areas

– Ships and ports: used for ship hoists and dock loading and unloading equipment.

– Construction and mining: lifting and hoisting, tension adjustment of mining machinery.

– Hardware rigging: often used with shackles, chains, hooks, etc.
